Akron Brass StreamMaster II Manual Fire Monitor System 2000 GPM (7600 LPM)
Akron Brass StreamMaster II Manual Fire Monitor System 2000 GPM (7600 LPM)
The Akron Brass StreamMaster II Manual Fire Monitor System 2000 GPM (7600 LPM) water cannon with its multiple patent pending design, provides efficient flows up to 2000 GPM (7600 LPM).
These firefighting monitors have a unique waterway design that provide balanced forces on the outlet and reduced friction for the stream resulting in exceptional fire suppression performance over a wide range of flows in a compact configuration.
Features:
- Compact industry-leading operating envelope (10.5", 267 mm)
- Lightweight Pyrolite construction
- Rotation range 355°
- Elevation range +90°, - 45°
Specifications:
The 2000 gpm rated monitor is to be a manually operated single waterway monitor constructed of lightweight Pyrolite. The monitor shall have a 4” (100 mm), 150 lbs. flanged inlet and 3-1/2” (89 mm) NH outlet. The monitor shall have cast-in turning vanes in each elbow. The monitor shall have permanently mounted handwheels for both horizontal and vertical rotation. The monitor is not to exceed 17-1/2” (446 mm) high and 10-3/4” (273 mm) wide. The vertical travel shall be from 45° below to 90° above horizontal with adjustable stops at -15° and +45°. The horizontal rotation shall be 355° with physical stops at ±45°, ±90°, ±135° and at ±157°.
| Style | 3481 |
| Warranty |  |
| Weight | 33.3 (15.1 kg) |
| Material | Pyrolite |
| Brand | StreamMaster |
| Width | 10 1/2'' (267 mm) |
| Height | 17 1/2'' (446 mm) |
| Inlet | 4" 150 lb. flange (Optional 3" flange) (DN100 PN16 flange) |
| Outlet | 3 1/2'' Male (Optional 2 1/2" Male) (89 mm (Optional 64mm)) |
| Flow (GPM) | 2000 |
| Flow (LPM) | 7600 |
