Description
FRC TankVision Pro 400
The TankVision Pro is the fire industry's first multicolor tank level display. It uses a pressure sensor to sense the amount of liquid in the tank and can be calibrated to accurately display the volume in tanks of all shapes and sizes.
Features:
The TankVision Pro is the fire industry's first multicolor tank level display. It uses a pressure sensor to sense the amount of liquid in the tank and can be calibrated to accurately display the volume in tanks of all shapes and sizes.
Features:
- Various Programmable multi-color tank level displays available
- More accurate tank level display
- Fractional scale standard, also available with percentage scale
- 9 LED level indicators with fractional scale
- 10 LED level indicators with percentage scale
- Programmable brightness control
- Full 180 degree wide-view, easy to see display
- The TankVision Pro is available for water, class A foam, and class B foam tanks. Each display has a distinctive color and style
Cab Miniature Displays:
- The cab miniature display has dimensions of 2.75 inches high by 1.5 inches wide
- It provides the option of mounting a remote display in the cab that uses a minimum of panel space
- An output signal from the primary display module is input to the cab miniature display and the volume of liquid in the tank is shown on the 5-LED display
Primary Displays for Foam:
- The TankVision Pro is available for water, class A foam, and class B foam tanks
- Each display has a distinctive color and style
- A single primary display can be connected to an unlimited number of color coded, full size remotes using the FRC datalink
Supplied with Unique Foam Tank Vent
- For use on sealed foam tanks.
- The vent is designed to relieve tank pressure at +/- 0.01 PSI which is important for proper display function (Conventional vents relief pressure is +/- 1.0 PSI)
- Vents are self-draining
- This stops splashing concentrate from entering the valve cavity and clogging the vent
Thin Wall Adapter:
For use on tanks where the walls are thin (less than or equal to 3/8"). Shown with pressure sensor mounted.
Remote Large Light Driver:
The TankVision Pro remote large light driver provides the option to power four 60 watt remote lights to show full, 3/4, 1/2, and 1/4 tank.
Standard Features:
- Flashing Warning when tank is below 25%
- Down-Chasing LEDs alert operator when tank is almost empty
- Self-Calibrating for any size or shape tank
- Self Diagnostic capabilities
- FRC Datalink allows for unlimited displays
- Rugged Waterproof cast aluminum housing
**More options are available. Please call for more information.
Details
SKU: |
FRC-WLA400 |
